Vox MINI GO 3 User Manual

The output signal from this jack is taken before the power amp, and the character of the amp cabinet is applied to it.
Connecting headphones to this jack will mute the internal speaker.
Be sure to make 3 vete,’ connection at the PHONES jack.
Rear Panel
Connector protection bar (VOX MINI GO 10/50)
Do not use this protection bar to carry this instrument. To carry the instrument, use the carry strap provided with this product.
25. DC 19V jack* (*DC 12V jack at VOX MINI GO 3/10) Connect this jack to the included AC adapter.
The AC adapter should only be used with the main unit. Do not use the adapter with other devices since doing so may cause a
malfunction.
26. DC 5V IN jack (USB Type-C connector)
Connect a commercially available mobile battery.
Noise may be heard when the power is supplied from a commercially available USB AC adapter, so use a mobile battery.
This terminal is only used for input. It cannot supply power to another device.
Not compatible with USB Power Delivery (USB PD).
27. FOOT SW jack (VOX MINI GO 10/50) Connect the dedicated footswitch VFS3. For details, refer to “Using the foot switch” on page 11.
Setup
1. Set the VOLUME knob (10), TRIM knob (3), and RHYTHM LEVEL knob (17) to the minimum level.
2. Connect the included AC adapter to the DC19V jack (DC 12V jack for VOX MINI GO 3/10) on the rear panel (26), then plug the adapter into an AC outlet.
To use an off-the-shelf mobile battery, connect it to the DC 5V IN jack (27) using a USB Type-C cable.
Use a mobile battery with an output of at least 1.5A. Depending on the mobile battery or USB Type-C used, the power may not be turned on, or the
battery may not be able to provide sufficient power.
When using a mobile battery, the output may be distorted or there may be noise.
3. Plug your guitar into the INPUT jack on the top panel. If you also plan to use a CD or MP3 player or a microphone, connect the player to the AUX IN jack,
or the microphone to the MIC IN jack on the top panel.
4. Press and hold down the Power button until the power LED lights up and the power turns on.
5. Slowly raise the VOLUME Knob to the desired level.
6. When turning off the power, press and hold down the Power button until the power LED turns off.
Using the stand (VOX MINI GO 10/50)

Vox MINI GO 3 Specifications

General

Tempo range	40 - 240 bpm
Amplifier class	-
RMS rated power	3 W
Number of speakers	1
Speaker driver size	5 \
Audio output channels	- channels
Preset rhythm patterns	33
Sound effects quantity	8
Microphone in	Yes
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Suitable for	Acoustic-electric guitar
Product color	Black
Volume control	Rotary
Power source type	AC, Battery

Weight and Dimensions

Depth	180 mm
Width	256 mm
Height	249 mm
Weight	3500 g
