6
Pivot to spindle: 258 - mm
Effective length: 273.4 - mm
Overhang: 15.4 - mm
Offset angle: 19.98 - degrees
Average RMS distortion: 0.31%
Setting the Azimuth
• Using the supplied aluminium rod placed into the groove behind the mounting screws on the
tonearm headshell.
• Azimuth is factory set to be level but you can adjust the arm wand by loosening the Azimuth
Set Screws on the side of the arm and slightly turn the wand.
