Plastic strap
Main landing gear
Gear mount
(plywood)
Ply gear mount
plate
Square plastic
3x20mm
3x20mm
Ply gear mount plate
Square plastic
Main gear (left)
Main gear (right)
Gear mount
(plywood)
Plastic strap
3x20mm screw..16
1- Fixed gear
