Vrisimo 500 Series - Top Shaft Assembly

17 www.vrisimo.com
#
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Description
Top Shaft Extension 1 3/8” x 12.5”
Top Shaft 1 3/8” x 10”
Top Shaft 1 3/8” x 16”
Top Shaft 1 3/8” x 22”
Complete Universal Assembly
Yoke, 1 3/8” Round Bore
Universal Cross Assembly
Complete Universal Assembly
Yoke 1 3/8” Round Bore, Keyed
Yoke 1 3/8” Six Spline
Universal Cross Assembly
Bearing Assembly 1 3/8” 2 Bolt
Top Shaft Safety Shield
Roll Pin, Univ. to Top Shaft (not pictured)
Key, 3/8” x 2” (not pictured)
Guard and Cover PTO Input Shaft
Guard and Cover Gearbox to Top Shaft
Guard and Cover Top Shaft Extension
Key 5/16” x 2” Pulley End (not pictured)
Roll Pin, Universal to Gearbox (not pictured)
Model
All
S-500-6
S-500-7
S-500-8
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
All
Part #
TS-1408
TS-1409
TS-1410
TS-1411
TS-1084
DS-2225
DS-2230
TS-1085
DS-2225
DS-2223
DS-2230
TS-1306
TS-1199
TS-1198
TS-1194
M-4014
M-4015
M-4017
TS-1179
TS-1198
Qty.
1
1
1
1
1
2
1
1
1
1
1
1
A/R
3
3
1
1
1
1
1
Year
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
1998+
Top Shaft Assembly
500 Series
8 9 7
6
11
3
10 1
16
15
14
2
(Under Shield)
4 5 4
