Vrisimo 500 Series - Cutter Drum Assembly

Cutter Drum Assembly
500 Series
#
1
2
3
4
4
5
5
6
6
7
8
9
10
10
10
11
Description
Bearing Assembly 2 7/16” 4 Bolt
Bearing Wire Guard
End Plate Slot Filler
Bolt, Hammer Hanging
Bolt, Hammer Hanging
Stover Nut
Castle Nut with Roll Pin Hole
Heavy Lock Washer
Heavy Lock Washer
Knife-Heat Treated
Spacer
Roll Pin
Cutter Drum-6’
Cutter Drum-7’
Cutter Drum-8’
Weld on Knife Mount
Model
All
All
All
All
All
All
All
All
All
All
All
All
S-500-6
S-500-7
S-500-8
All
Part #
CD-1825
CD-2511
CD-2195
CD-2550
CD-40EX-30
CD-2560
CD-40EX-34
CD-2570
CD-40EX-33
CD-2500
CD-40EX-32
CD-40EX-35
CD-2516
CD-2517
CD-2518
CD-2512
Qty.
2
2
2
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
A/R
1
1
1
A/R
Year
1998+
1998+
1998+
1998 - 2004
2005+
1998 - 2004
2005+
1998 - 2004
2005+
2005+
1998 - 2005+
2005+
1998+
1998+
1998+
1998+
For models with serial number VT50006219-7 and earlier, use 4.5” bolt and stover nut.
3
2
1
7 5 8 10
4 6
19 www.vrisimo.com
