VSPHOENIX S - VSPHOENIX S Component Identification; Front and Back View Components

VSPHOENIX S MANUAL 54 VSPHOENIX S Manual
Name of each part of VSPHOENIX S Name of each part of VSPHOENIX S
VSPHOENIX S SPEC Name of each part of VSPHOENIX S
Speaker(Left)
27 inch LED Monitor
Speaker(Right)
Camera(Player)
Camera(Target)
Target
23 inch LED Monitor
Arrow Buttons
Woofer
Lower LED
Dard Reader
Select Button
Lower Handle
Move Wheels
Control Feet
Upper Handle
Back Door
KEY
Power Switch
LED THROW
Vents
A/C Power Inlet
Fuse (5A)
Lan
Reset Switch
(Use when a main board
BIOS is an error)
Right View
Front Back
Left View
KEY
