VTech 4-in-1 Stroll & Grow Tek Trike - Page 7

7
7
7
6. Then, screw them together, using
2 T7 screws. Then, set it aside.
T7 (x2)
5. Push the storage bin (F) into the
frame (C)untilit’ssecure.
C
F
10. Place the seat (N) onto the frame (B).
N
B
9. Install the seat belt (P1) for seat (N).
8. Put the nuts (with T10) in place and
then screw the T2 screws into the nuts.
T2 (x2)
7. Align the opening of (D) with frame
(B) and place (D) into Stage 1 of
frame (B).
B
D
STAGE 1,2
STAGE 3
STAGE 4
4
P3
T10
