VTech 4-in-1 Stroll & Grow Tek Trike - Page 8

8
8
8
12. Align the opening of frame (B)
with frame (A).
A
B
16. Press the push button inward
as you push the removable seat
back (E) into the seat (N).
14. Push the frame (C) into the
frame (B).
C
B
T3 (x1)
T10
15. Using T10 fasten T3 with screw
and nut.
The screw must
be placed from
the back.
13. Then, fasten T9 to frame (B) with
2 T3 screws and nuts.
T3 (x2)
T9
T9
B
A
T7 (x4)
11. Then, screw them together using
4 T7 screws.
N
E
