8
Getting Started
Wall Mounting
You can obtain a wall mounting accessory by calling 1-800-595-9511. In Canada,
call 1-800-267-7377
.
The Wall Mount bracket is designed for use on standard Wall Mount plates only.
1. Line up the tabs on the wall mount bracket with the slots on the bottom of the
Base Unit. Snap the bracket firmly in place.
2. Plug the AC adapter into an electrical outlet, and the DC connector to the
Base. If the battery pack has not been previously charged, place the Hand-
set in the cradle, and allow it to charge for 12 hours.
3. Connect the telephone line cord to the jack on the Base, and the other end
to the wall jack.
4. Mount the Base on the wall. Position the Base Unit so the mounting studs
will fit into the holes on the wall mount bracket. Slide the Base Unit down on
the mounting studs until it locks into place.
a) Align holes on bracket with
mounting studs on wall plate.
b) Slide bracket down on studs
until it locks into place.
Installation
