Mount the baby monitor - Method 1
If you drill the holes into a stud, go to
step 3.
-OR-
If you drill the holes into an object other
than a stud, insert the wall anchors into
the holes. Tap gently on the ends with a
hammer until the wall anchors are flush
with the wall.
Align the wall mount and screws
with the holes in the wall as shown.
Tighten the screw in the middle
hole first, so that the wall mount
position is fixed. You can tighten
the other screw in the top hole.
Place the baby unit on the wall mount.
Tighten the screw into the threaded
socket at the bottom to secure the
baby unit.
Check for reception strength and
camera angle before drilling the
holes.
Place the wall mount on a wall and
then use a pencil to mark the top and
the bottom holes as shown.
Remove the wall mount and drill two
holes in the wall (7/32” drill bit).
