CHAPTER 5
TL-6.5 Specifications
Vacuum Tube Complement 2 x 12AU7
Inputs
3 pairs balanced/XLR or RCA single-ended
3 pairs single-ended/RCA
Outputs
1 pair balanced out
2 pairs single-ended RCA out
2 pairs single-ended RCA buffered Tape Out
Remote Control Functions
Power
Source Select
Volume up/down
Mute
Fade
Balance Control
Phase Reverse
Gain 14 dB single ended, 20dB balanced
Output Impedance 25 Ohms (Max 195 ohms at 10Hz)
Input Impedance 50K Ohms
Frequency response + 0 - 1 dB
1 Hz - 200KHz into (20Hz – 100kHz +0–1dB into
600 ohms with 900pf 20’ interconnect cable)
Maximum Output Voltage < 1%
THD
30 Volts 10Hz – 200kHz into 600 ohms at 1%THD
Channel Separation > 100 dB @ 1KHz (>80 dB @ 20kHz)
Power Consumption 150 Watts
Weight
50 lbs (22.72 Kg) Fully packed in one box
Unpacked weight: 45 lbs
