CHAPTER 5
Specifications
TP2.5 Phono Preamplifier
Vacuum Tube Complement 1x12AT7
2x12AX7(MM)
1x12AU7(MC)
T.H.D. 20 Hz - 20 KHz 0.1% 1KHz
Signal to Noise Ratio -56 dB (MM)
-50 dB (MC)
Maximum Output Voltage 20 Volts
Gain 42 dB (MM)
56 dB, 62 dB (MC)
Load 47K Ohms, 100K Ohm (MM)
100 ohm, 250 ohm, 470 ohm, 1K, 5K,
47K ohm (MC)
Power Consumption 25 Watts
Primary Mains Fuse Rating 1A Slo Blo Ceramic (120Volt AC)
.41 A Slo Blo Ceramic (240 Volt AC)
Dimensions 19” wide x 15” deep x 4” high
48.25 x 35.5 x 9.5 cm
Weight 25 lbs (11.34 Kg) packed
TP2.5 Preamplifier Owner’s Manual
