Operating Instructions
1. When picking up a bale, it is best to tilt the JM handler forward slightly so the top of the
mainframe (C) touches the top of the bale. By having the bale touching at point A, B & C
ensures a tight grip at seen in figure 1
Figure 1.
2. Before lifting the bale, squeeze the handler fully. When the bale is initially lifted squeeze the
handler again, as more squeeze can be achieved when the bale is off of the ground.
3. If travelling a sizable distance, it is best to tilt the handler back to allow the bale to site into
the handler as seen in figure 2.
Figure 2.
