VW TR Series - Technical Specification

5
JM AGRI DESIGN. Derrymore East, Tralee, Co. Kerry, Ireland. M: +353 (0)87 2193062 E: jmoynihan@jmagridesign.com. 5
TR-4 Technical Specification
Technical specification
Length (closed)
1.34m
Length (opened)
1.835m
Width
1.25m
Height (closed)
1.584m
Height (opened)
2.052m
Weight
250kg
Max bale length
1.3m
Max bale height
1.55m
Max bale weight
1200kgs
Hydraulic connection
Double acting connection
Oil pressure min & max
180bar/210bar
