4
GRAPHIC SYMBOLS
Your incubator has been provided with a display of graphic symbols on the control panel
which is designed to help in identifying the use and function of the available user adjustable
components.
2.1 Indicates that you should consult your manual for further
description or discussion of a control or user item.
2.2 Indicates "Temperature"
2.3 Indicates "Over-Temperature Safety".
2.4
C° Indicates "Degrees Centigrade".
2.5 CO
2
Indicates "Carbon Dioxide".
2.6 Indicates "Gas" (CO
2
for this unit.)
2.7 Indicates "AC Power On".
Sectio
2
