W Box Technologies 0E-13BF40 - Specifications

20
Specifications
Model
0E-13BF40
0E-21BF40
0E-31BF40
Camera
Image Sensor
1/3" Progressive Scan CMOS
1/2.8" Progressive Scan CMOS
1/3" Progressive Scan CMOS
Min. Illumination
0.01Lux @ (F1.2, AGC ON) ,0 Lux
with IR
0.01Lux @ (F1.2, AGC ON) ,0 Lux
with IR
0.028Lux @ (F2.0, AGC ON) ,0 Lux
with IR
0.07Lux @ (F1.2, AGC ON) ,0 Lux
with IR
Shutter Speed
1/3 s to 1/100,000 s
Lens
4mm@ F2.0
Angle of view: 73.1°
Angle of view: 85°
Angle of view: 79°(1920 × 1080)
Angle of view: 70°(2048 × 1536)
Day &Night
IR cut filter with auto switch
Digital Noise Reduction
3D DNR
Wide Dynamic Range
Digital WDR
Compression Standard
Video Compression
H.264/ MJPEG
Video Bit Rate
32 Kbps – 8 Mbps
32 Kbps – 12 Mbps
Max. Resolution
1280 x 960
1920 × 1080
2048 × 1536
Frame Rate
30 fps (1280 × 960), 30 fps (1280 x
720), 30 fps (704 x 576),
30 fps (640 x 480)
30fps(1920 × 1080), 30fps (1280 ×
960), 30fps (1280 × 720)
20fps (2048 × 1536), 30fps (1920 ×
1080), 30fps (1280 × 720)
Image Settings
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
Backlight compensation
Yes, zone optional
Network
Network Storage
NAS (Support NFS,SMB/CIFS)
Alarm Trigger
Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage
exception
Protocols
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General
One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark,
IP address filtering, Anonymous access
Standard
ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface
1 RJ45 10M/100M Ethernet interface
Reset Button
Yes
General
Operating Conditions
-30 °C – 60 °C (-22 °F – 140 °F); Humidity 95% or less (non-condensing)
Power Supply
12 V DC ± 10%; PoE (802.3af)
Power Consumption
Max. 7 W
Ingress Protection level
IP66
IR Range
30 meters
Dimensions
60.4×76.9×139.28 mm (2.4” × 3.0” × 5.5”)
Weight
500g (1.1 lbs)
