W'eau WFI-005 - Electrical Connection; Condensation Drainage

- 8 -
3.6 Electrical connection
* Suggested power cable specification
Model
Power Cable Specification
WFI-005/007/010
3*1.5 mm²
WFI-013/017
3*2.5 mm²
WFI-021
3*4 mm²
Terminal
Terminal cable max. 4 mm
²
* Electrical connection
Position L,N and is for the power connection of our heat pump.
Position P1 and P2 is for the Single phase water pump.
3.7 Condensation drainage
When machine running, there will be some condensation water on the base tray, which is the normal
situation. Please you can use the drainage jet and hose at the bottom of machine to drain the
condensation water. See below.
