Page 6 of 14
2391, S.5
September, 2004
Repair Track Maintenance
Figure 1 - ABDX Service Portion
Alternate Configuration
of Release Valve
P
P
X
“P” designates Vibration Protection
ABDX cast on top cover
“X” stamp
