WABCO ABDX - ABDX Emergency Portion; ABDX-L Emergency Portion

Page 7 of 14
2391, S.5
September, 2004
Repair Track Maintenance
Figure 2 - ABDX / ABDXL Emergency Portions
ABDX Emergency Portion
ABDX-L Emergency Portion
S
P
P
S
ABDX
ABDX
L
P
P
L
ABDX-L
ABDX-L
Internal
Vent Protector
ABDX-L cast on
vent valve cover
ABDX-L cast on
vent
valve cover
ABDX cast on
vent valve cover
ABDX cast on
vent valve cover
“S” designates Short Car
“P” designates Vibration Protection
“L” designates Long Car
