17
Fault codes and their meaning
EN
1069 Tire pressure
1070 Vehicle deceleration monitoring
1204 No loads connected
1351 Air Compressor
1792 Trailer ABS warning lamp
1807 Data connection SAS (steering-wheel angle sensor)
1809 Lateral accelerometer
1810 Longitudinal accelerometer
2622 Hill Start Aid system
3509 Power supply (sensors, stability control)
520210 Electronic stability control system (CAN data connection / ESC module)
520211
Electronic stability control system (CAN data connection / steering-wheel angle sensor
/ ESC module)
520310 Electronic Air Dryer
520400 Extended CAN messages / CAN vehicle bus
Towing vehicle and bus ABS
FMI FAULT DESCRIPTION
0 Data valid, but above normal operation range (most severe level)
1 Data valid, but below normal operation range (most severe level)
2 Data erratic, intermittent or incorrect
3 Voltage above normal, or shorted to UBatt
4 Voltage below normal or shorted to ground
5 Current below normal or open circuit
6 Current above normal (grounded circuit, internal short circuit)
7 Mechanical system is not responding correctly or is maladjusted
8 Abnormal frequency, pulse width or period
9 Timeout or cabling
10 Implausible input signal
11 Failure mode not identiable / root cause unknown
12 Bad intelligent device or component
13 Signal out of valid range
14 Implausible value
VCSII
SPN AFFECTED COMPONENT
3 Rotational speed sensor c
4 Rotational speed sensor d
5 Rotational speed sensor e
6 Rotational speed sensor f
7 Solenoid valve A
