Wacker Neuson 1001 - Locking the Control Levers (2001)

BA 1001/1501/2001 us – Edition 3.3 * 12001b330.fm 3-39
Operation
Fasten control lever lock A with split pin B.
Locking the control levers (2001)
Fold back control lever lock A.
Fasten control lever lock A with split pin B.
Fig. 63: Locking the control levers (1001/1501)
B
A
Fig. 64: Locking the control levers (2001)
B
A
Fig. 65: Locking the control levers (2001)
B
A
