BA 1404 en – Edition 2.7 * 1404b320.fm 3-11
Operation
Indicator light (yellow) – preheating
Comes on, when the ignition key is in pos. 2 .
A glow plug preheats the air in the combustion chamber of the engine when the key is in
this position.
Control light (green) – speed level 2 (display 2)
(starting from serial number WNCE0901KPAL02194)
Comes on when speed level 2 is selected.
Coolant temperature (display 2)
Indicates the current coolant temperature of the engine.
When the segments reach the red range, the control light Acomes on.
• Stop the engine
• Let the engine cool down and check the coolant level.
Fuel level indicator
