Wacker Neuson 50Z3 User Manual

3-52 BA 50Z3/6003 en – Edition 4.3 * * 5003b330.fm
Operation
☞ Release levers A and make them lock into place in both recesses C.
Closing the front window
☞ Press levers A on the left and right, and pull the front window downward with both han-
dles B.
☞ Press levers A on either side and engage them in the lock.
C
A
Fig. 114: Opening the front window
Fig. 115: Closing the front window
A
B
Fig. 116: Closing the front window
A
