Specifications
Main data Model 50Z3
A Height 2570 mm (8'-5'')
BWidth 1990 mm (78 in)
C Transport length 5500 mm (18'-1'')
D Max. digging depth (short stick) 3500 mm (11'-6'')
E Max. digging depth (long stick) 3750 mm (12'-4'')
F Max. vertical digging depth (short stick) 2670 mm (8'-9'')
G Max. vertical digging depth (long stick) 2885 mm (9'-6'')
H Max. digging height (short stick) 5300 mm (17'-5'')
I Max. digging height (long stick) 5460 mm (17'-11'')
J Max. tilt height (short stick) 3680 mm (12'-1'')
K Max. tilt height (long stick) 3840 mm (12'-8'')
L Max. digging radius (short stick) 5985 mm (19'-3'')
M Max. digging radius (long stick) 6225 mm (20'-5'')
N Max. reach at ground level (short stick) 5860 mm (19'-3'')
O Max. reach at ground level (long stick) 6105 mm (20'-0'')
P Min. tail end swivelling radius 995 mm (39 in)
Q Max. boom displacement to bucket centre (right side) 960 mm (38 in)
R Max. boom displacement to bucket centre (left side) 895 mm (35 in)
S Max. lift height of stabilizer blade over ground 415 mm (16 in)
T Max. scraping depth of stabilizer blade below ground surface 455 mm (18 in)
U Running gear length 2500 mm (98 in)
V Max. tilting angle of boom to the right 61°
W Max. tilting angle of boom to the left 65°
X Track width 400 mm (16 in)
Max. breakout force at bucket tooth 33.80 kN (7598 lbf)
Max. tearout force (short stick) 26.60 kN (5980 lbf)
Max. tearout force (long stick) 23.50 kN (5283 lbf)
Max. tail end lateral projection over tracks 0 mm (0 in)
