13 Technical data
56
Designation Unit DPU 3060Hets DPU 3070H
Item no. 0610302 0610041
Length x width x height
(guide handle in transport
position)
mm
(ft)
733 x 600 x 1,170
(2.4 x 1.9 x 3.8)
733 x 700 x 1,170
(2.4 x 2.3 x 38)
Operating weight kg (lb) 215 (474) 195 (430)
Advance and reverse
travel
m/min
(ft/min)
23
(75.5)
18
(59.1)
Area capacity m²/h
(ft²/h)
828
(8913)
756
(8138)
Maximum permissible tilt ° 25
Sound pressure level L
pA
at operator's station
dB(A) 95
Total vibration value of the
acceleration a
hv
*
* Determined according to DIN EN ISO 5349.
m/s
2
3.2 3.2
Uncertainty of measure-
ment of the vibration total
value of the acceleration
ahv
m/s
2
1.0
