13 Technical data
58
Drive motor
Exciter
Hydraulic
Designation Unit DPU 25.. DPU 30.. DPU 37..
Manufacturer HATZ
Type 1B20 1B30
Engine displacement cm³ (in³) 243 (14.8) 347 (21.2)
Rated output*
* Equivalent to the installed power output in accordance with the directive 2000/14/EC.
kW 3.1 4.2
Operating power kW 1.5 1.9 1,7
Operating blade speed rpm 2,800
Fuel type
Diesel according to DIN EN 590
Fuel consumption l/h (qt/h) 0.4 (0,42) 0.6 (0.63)
Tank capacity l (qt) 3.0 (3.17) 5.0 (5.28)
Oil specification
Fuchs Titan Unic 10W40 MC
(SAE 10W40)
Oil quantity
l (qt) 0.9 (0,95) 1.1 (1.16)
Designation Unit DPU 25.. DPU 30.. DPU 37..
Vibrations rpm (Hz) 5,400 (90)
Centrifugal force kN 25 30 37
Oil specification Fuchs Titan Unic 10W40 MC
(SAE 10W40)
Oil quantity l (qt) 0.6 (0.63)
Designation Unit DPU 25.. DPU 30.. DPU 37..
Oil specification
Fuchs Renolin MR 520
Oil quantity
l (qt) 0,4 (0.42)
