9 Maintenance
47 100_0202_mt_0011.fm
Top up motor oil
1. Remove dirt accumulation in the area of the oil filler opening.
2. Remove cover of the oil filler opening.
3. If necessary, fill with engine oil until the upper mark of the oil-level dipstick is reached – for oil
specification, see Technical Data chapter.
4. Put the cover back on the oil filler opening and press firmly.
5. Wipe away any spilled oil.
9.4.4 Replace engine oil
Drain the engine oil and replace the oil filter
1. Open both protective hoods.
2. To protect the floor from leaking oil, cover the working surface with an impermeable foil.
3. Place a sufficiently large collecting container under the oil filter.
4. Unscrew and remove oil filter – when unscrewing, collect any leaking oil.
5. Place collecting container under the oil drain plug.
6. Loosen oil drain plug.
7. When the oil has completely drained, screw in the oil drain plug and tighten.
8. Screw in new oil filter and tighten by hand.
NOTE
The amount of oil between the upper and lower mark is between 0.6 l (DPU 80) and 1.0 l
(DPU 100).
NOTE
Dispose of oil in accordance with the applicable provisions for environmental protection.
NOTE
Change oil in lukewarm engine so that the oil can drain completely.
Item Designation Item Designation
1 Cover of the oil filler opening 4 Oil filter
2 Oil-level dipstick 5 Oil drain plug
3 Label
