Oil Injection (if equipped) Rammer Repair
118 wc_tx001549gb.fm
7.1.3 Check the continuity of the float switch by measuring across the
connector.
Does the float switch have continuity?
7.1.4 Reconnect the float switch.
7.1.5 Reinstall the carburetor guard.
7.2 Replacing the Float Switch (2010 and later models)
Requirements
• New float switch
• 2-cycle engine oil
Removal
Perform the procedure below to remove the float switch.
7.2.1 Remove the silencing cover. See topic
Removing the Silencing Cover.
7.2.2 Remove the carburetor guard (a).
7.2.3 Disconnect the float switch wiring
(c).
7.2.4 Locate the oil tank
(d).
Yes ____ No ____
The float switch is OK. The float switch has failed; replace it.
To Next Page
