Repair Engine and Upper Machine Components
wc_tx001546gb.fm 41
4.7.5 Install the fuel tank with screws (a). Torque the screws to 9 Nm (6
ft.lbs.).
4.7.6 Install the throttle control bracket. See topic Replacing the Stop Switch.
4.7.7 Install the throttle control. See topic
Replacing the Throttle Control.
4.7.8 Install the silencing cover. See topic Replacing the Silencing Cover.
Result
The replacement procedure is now complete.
