BA 5001-6001 US – Edition 1.2 * 6001b330.fm 3-39
Operation
3.25 Locking the control lever (6001)
CAUTION
Personal injury hazard. An unlocked control lever may cause unintentional
actuation of the dump bucket.
☞ Lock the control lever for the dump bucket while traveling.
Lock as follows:
☞ Remove split pin A from lock B.
☞ Fold lock B to the front.
☞ Insert split pin A in lock B.
Unlock in the reverse order!
Fig. 63: Locking the control lever
A
B
