Wacker Neuson DV100 User Manual

9-18 BA D24 en/us* 1.0 * D24_1_0_900.fm
9 Technical data
DV60
mm (in)
DV90
mm (in)
DV100
mm (in)
A1 3078 (10'-1'') 3083 (10'-1'') 3083 (10'-1'')
A2 2938 (9'-8'') 2944 (9'-8'') 2945 (9'-8'')
A3 3617 (11'-10'') 3620 (11'-11'') 3620 (11'-1'')
A4 3302 (10'-10'') 3307 (10'-10'') 3307 (10'-10'')
A5 2400 (95) 2405 (95) 2405 (95)
B1 4799 (15'-9'') 4991 (16'-5'') --
B2 4727 (15'-6'') 4919 (16'-2'') --
B3 4548 (14'-11'') 4722 (15'-6'') 4760 (15'-7'')
B4 4476 (14'-8'') 4650 (15'-3'') 4688 (15'-5'')
C1 2440 (96) 2440 (96) 2420 (95)
C2 2533 (100) 2533 (100) 2533 (100)
C3 1221 (48) 1221 (48) 1221 (48)
C4 2218 (87) 2453 (97) --
C5 2328 (92) 2524 (99) 2524 (99)
D 1790 (70) 1920 (76) 1920 (76)
E 2485 (97) 2700 (8'-10'') 2700 (8'-10'')
F 370 (15) 358 (14) 358 (14)
G1 456 (18) 457 (18) --
G2 565 (22) 520 (21) 549 (22)
G3 1157 (46) 1157 (46) 1157 (46)
H1 1689 (67) 1728 (68) --
H2 1981 (78) 2230 (88) --
H3 1673 (66) 1724 (68) 1745 (69)
H4 2028 (80) 2104 (83) 2184 (86)
H5 3639 (11'-11'') 3980 (13'-1'') --
H6 2463 (97) 2723 (8'-11'') 2718 (8'-11'')
H7 1422 (56) 1444 (57) --
Y 69 (3) 152 (6) --
K1 48° 40.1° --
K2 50° 48° 48°
K3 90° 90° --
