7 Maintenance
Preparing lubrication
1. Stop the machine on firm, level and horizontal ground.
2. Lower the skip. Check the middle position if the machine is equipped
with a swivel skip see page 5-27 “Middle position of swivel skip.”
3. Stop the engine.
4. Remove the starting key and carry it with you.
5. Safely store all loose objects.
6. Close the windows and doors (cabin option).
7. Close and lock all covers.
8. Attach a warning label to the control elements (for example “Machine
being serviced, do not start”).
Wait at least 10 minutes after stopping the engine.
Keep all lubrication points clean and remove any escaping grease.
