7 Maintenance
Checking the engine oil level
1. Stop and park the machine. Stop the engine – see “Preparing
lubrication” on page 7-8.
2. Open the maintenance flap on the right.
3. Clean the area around the oil dipstick with a lint-free cloth.
4. Pull out oil dipstick A (Tier III) or B (Tier IV) and clean it with a lint-free
cloth.
5. Push oil dipstick A or B back in as far as possible.
6. Withdraw oil dipstick A or B again and read off the oil level.
➥ The oil level must be between the MIN and MAX marks.
➥ Add engine oil if necessary.
7. Slide in oil dipstick A or B completely.
8. Close and lock the maintenance flap on the right.
