BA EZ17 en* 1.1 * ez17b510.fm 5-27
Operation 5
Additional control circuits
AUX II (option)
Set the desired flow rate with the rotary switch B.
Fig. 112
B
Fig. 113
22
Oil flow Position
To the line on the left Press gate 22 to the left
To the line on the right Press gate 22 to the right
