6 Transportation
1. Observe chapter Transportation on page 2-13.
2. Secure the transport vehicle with chocks to prevent it from rolling.
3. Position the ramps at the smallest possible angle. Ensure that the
grade does not exceed 15° (27 %).
4. Use access ramps and transport surfaces with an antiskid surface
only.
5. Ensure that the loading area is clear and access to it is not obstructed
(superstructures, for example).
6. Start the engine.
7. Raise the boom and the stabilizer blade to avoid touching the access
ramps.
8. Carefully drive the machine onto the middle of the transport vehicle.
9. Move the machine to transport position.
- Position the boom straight ahead at the center of the machine.
- Lower the boom and the stabilizer blade.
10.Stop the engine.
11.Raise the control lever base.
12.Remove the starting key and carry it with you.
13.Leave the vehicle and close and lock all covers.
14.Firmly fasten the machine on the loading area with tie-downs A and B
with slings C of appropriate size. Observe legal rules and regulations.
