BA EZ17 en* 1.1 * ez17w700.fm 7-9
Maintenance 7
Green grease nipples mean: lubrication every 50 hours or once a week.
Blue grease nipples mean: lubrication every 10 hours or daily.
Position Lubrication point Interval Quantity
1. Boom Daily 2
2.
Stick cylinder Daily 2
3.
Bucket cylinder Daily 3
4.
Boom cylinder Daily 2
5.
Joint rod Daily 1
6.
Bucket pin Daily 2
7.
Shovel arm Daily 1
8.
Swiveling console Daily 2
9.
Stabilizer blade Every week 4
10.
Ball bearing race Every week 1
11.
Swiveling cylinder Daily 2
12.
Control lever base Every week 3
13.
Hydraulic quickhitch (option) Daily 2
14.
Powertilt (option) Daily 4
