9-2 BA EZ17 en* 1.1 * ez17t900.fm
9 Technical data
The machine has about 17 % less output at altitudes over 800 m (2625 ft)
above see level. However, this does not affect excavator operation
(Yanmar 3TNV80F-SSNS1).
Engine EZ17
Product Yanmar diesel engine
Type 3TNV80F-SSNS1
Design Water-cooled 3-cylinder diesel engine
Intake system Naturally aspirated engine
fuel injection system Indirect
Engine management Mechanical
Displacement 1266 cm
3
(77.3 in
3
)
Nominal bore and
stroke
80 x 84 mm (3.2 x 3.3 in)
Power
12.8 kW at 2200 rpm
(17.2 hp at 2200 rpm)
Max. torque
65.8 Nm at 1600 rpm
(48.5 ft.lbs./1,600 rpm)
Max. engine speed
without load
2200 +/− 25 rpm
Idling speed 1300 +/− 25 rpm
Starting aid Glow plugs (preheating time 4 seconds)
Exhaust values
according to
EPA – Tier IV final (for NTE/NTRC cycle)
