9-18 BA EZ17 en* 1.1 * ez17t900.fm
9 Technical data
All table values are specified in kg (lbs), in horizontal position on firm and
level ground without bucket or attachment (for example a breaker).
The machine’s lift capacity is restricted by the settings of the pressure
limiting valves, the hydraulic output and the hydraulic system’s stabilizing
features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is
exceeded.
Calculation basis: according to ISO 10567.
Setting pressure on boom cylinder: 22500 kPa (3,263 psi)
The lift capacity applies to machines under the following conditions:
• Fuel, lubricants and coolants at the prescribed levels
• Full fuel tank
• Canopy
• Machine at operating temperature
• Operator weight 75 kg (165 lbs)
