Technical data 9
EZ17
A Height 2360 mm (93 in)
B1 Canopy width 885 mm (35 in)
B2 Upper carriage width 980 mm (39 in)
B3 Width with retracted travel gear 990 mm (39 in)
B3 Width with extended travel gear 1300 mm (51 in)
C1 Transport length (short stick) 3585 mm (11'-9'')
C2 Transport length (long stick) 3550 mm (11'-8'')
D1 Max. digging depth (short stick) 2330 mm (92 in)
D2 Max. digging depth (long stick) 2490 mm (8'-2'')
E1 Max. vertical digging depth (short stick) 1715 mm (68 in)
E2 Max. vertical digging depth (long stick) 1865 mm (73 in)
F1 Max. digging height (short stick) 3465 mm (11'-4'')
F2 Max. digging height (long stick) 3580 mm (11'-9'')
G1 Max. tilt-out height (short stick) 2440 mm (96 in)
G2 Max. tilt-out height (long stick) 2550 mm (8'-4'')
H1 Max. reach at ground level (short stick) 3850 mm (12'-8'')
H2 Max. reach at ground level (long stick) 4000 mm (13'-2'')
K1 Max. digging radius (short stick) 3900 mm (12'-10'')
K2 Max. digging radius (long stick) 4050 mm (13'-3'')
M Max. boom displacement to bucket center (right side) 535 mm (21 in)
N Max. boom displacement to bucket center (left side) 425 mm (17 in)
O Max. lift height of stabilizer blade over ground 390 mm (15 in)
P Max. scraping depth of stabilizer blade below ground surface 275 mm (11 in)
Q1 Distance between bucket and stabilizer blade (short stick) 332 mm (13 in)
Q2 Distance between bucket and stabilizer blade (long stick) 260 mm (10 in)
R1 Min. tail end swiveling radius 650 mm (26 in)
R1H Min. tail end swiveling radius (with extra weight) 725 mm (29 in)
R2 Boom swivel radius (center) 1625 mm (64 in)
R3 Boom swivel radius (right) 1515 mm (60 in)
R4 Boom swivel radius (left) 1370 mm (54 in)
S Total running gear length 1605 mm (63 in)
T Running gear length (Turas front idler) 1225 mm (48 in)
W1 Max. tilting angle of boom to the right 57°
W2 Max. tilting angle of boom to the left 65°
X Track width 230 mm (9 in)
Y1 Stabilizer blade width 990 mm (39 in)
Y2 Stabilizer blade width with extension 1300 mm (51 in)
Z Stabilizer blade height 230 mm (9 in)
