Putting into operation 4
Horizontal adjustment
1. Sit down on the operator seat.
2. Pull lever B upward and lock seat into place in the required position.
Backrest adjustment
Sit down on the operator seat.
Backrest inclination to the rear:
• Turn button toward +.
Backrest inclination to the front:
• Turn button toward −.
?
Fig. 48
B
Fig. 49
C
+
-
