BA E16 en* 1.0 * E16_10_700.fm 7-9
Maintenance 7
Preparing lubrication
1. Stop the vehicle on firm, level, and horizontal ground.
2. Position the boom straight ahead at the center of the vehicle.
3. Lower the boom and the stabilizer legs to the ground.
4. Stop the engine.
5. Operate the control lever repeatedly to release the pressure in the
hydraulic system.
6. Raise the control lever base.
7. Remove the starting key and carry it with you.
8. Safely store all loose objects.
9. Close the windows and doors.
10.Close and lock all covers.
11.Attach a warning label to the control elements (for example “Machine
being serviced, do not start”).
Wait at least 10 minutes after stopping the engine.
Keep all lubrication points clean and remove any escaping grease.
