Wacker Neuson E16-02 User Manual

9-20 BA E16 en* 1.0 * E16_10_900.fm
9 Technical data
Legend
Designation Explanation
A Reach from live ring center
B Load hook height
max Authorized lift capacity with horizontal boom
I
Vehicle in travel direction, front dozer blade, dozer
blade down, loss of dozer blade contact with ground
II Vehicle 90° to travel direction, dozer blade up
III
Vehicle in travel direction, front dozer blade, dozer
blade up, loss of front axle contact with ground
IV
Vehicle in travel direction, rear dozer blade, dozer blade
up, loss of front axle contact with ground
