BA E16 en* 1.0 * E16_10_900.fm 9-35
Technical data 9
Legend
Authorized lift capacity applies to entire swiveling range of 360°.
All table indications in kg (lbs.) and horizontal position on firm and level
ground without bucket or exchangeable attachment.
The vehicle’s lift capacity is restricted by the settings of the pressure
limiting valves, the hydraulic output and the hydraulic system’s stabilizing
features.
Neither 75% of the static tilt load nor 87% of the hydraulic lift capacity is
exceeded.
Calculation basis: according to ISO 10567.
ET35: 24,000 kPA (3481 psi)
EZ36: 24,000 kPA (3481 psi)
Lift capacities apply to vehicles under the following conditions:
• Lubricants and engine/vehicle fluids at the mandatory levels
• Full fuel tank
• Machine at operating temperature
• Operator weight 75 kg (165 lbs.)
Designation Explanation
X Reach from live ring center
Z Load hook height in the respective range
max Authorized lift capacity with horizontal boom
L Stick short/long
