BA E16 en* 1.0 * E16_10_300.fm 3-15
Introduction 3
Meaning
Indication of sound power level produced by the vehicle.
L
WA
= sound power level
ET35/EZ36 Tier III: 95 dB
ET35/EZ36 Tier IV: 94 dB (only tier IV EU)
Position
At the front left of the chassis
Meaning
Lubrication interval
Position
At the front left of the chassis
Meaning
Hydraulic functions active or locked
Position
On control lever base
Fig. 30 (symbolic representation)
