Maintenance RD 7
40 wc_tx000295gb.fm
Upper handle parts list
Ref. Part No. Qty. Description
Measurement
and Torque
15 0112307 1 Handle
16 0155442 1 Rod
20 0112351 1 Spring
28 0155441 1 Disc
77 0112391 2 Bearing 20 x 20
132 0010367 4 Lock nut M8
137 0010622 10 Flat washer B8,4
141 0011310 2 Hex head screw M8 x 85
25 Nm / 18 ft.lbs
145 0011346 2 Hex head screw M8 x 65
25 Nm / 18 ft.lbs
