WACO 2609C - Temperature Specifications; %Duty Cycle and Frequency Specifications

15
%Duty Cycle
Range
5% to 95%
Resolution
0.1%
Accuracy ( 5V logic)
±(2.0% rdg+10d)
>10us
Frequency range: 5% to 95% ( 40Hz to 20kHz )
The readings of % DUTY CYCLE measurements will show on the sub-
display.
Overload protection: 600V DC or AC rms
Pulse Width
Frequency
Resolution
0.01Hz
0.1Hz
1Hz
10Hz
100Hz
1KHz
Range
66Hz
660Hz
6.6KHz
66KHz
660KHz
1MHz
Trigger Level
>3.5V
>3.5V
>3.5V
>3.5V
>3.5V
>3.5V
Minimum Input Range: > 10Hz
Minimum pluse width: > 1us
Duty cycle limits: > 30% and < 70%
Overload protection: 600VDC or AC rms
Accuracy
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
±(0.1% rdg+5d)
Temperature
Range
0°C ~ 400°C
-20°C ~ 0°C, 400°C ~1000°C
32 °F ~ 750 °F
-4°F ~ 32°F,750°F ~1832°F
Resolution
1°C
1°C
1°F
1°F
Accuracy
± (1.0% rdg +2°C)
± (2.0% rdg +3°C)
± (1.0% rdg +4°F)
± (2.0% rdg +6°F)
Sensor type
K-type
Thermocouple
Overload protection: 60V DC or 30V AC rms
