Technical description
32
When used on boats, the cooler can withstand a constant heel
(inclination) of 30°.
Scope of functions:
z Intelligent battery monitor for protecting the vehicle battery
z Display with temperature gauge
z Temperature adjustment
with two keys in 1 °C (2 °F) increments
z Detachable carrying handles
5.2 Control and display elements
Lock for lid: fig. 2 1, page 3
Control panel (fig. 3, page 3)
Item Description Explanation
1ON
OFF
Switches the cooler on or off when the
button is pressed for one to two seconds
2 POWER Operating display
LED lights up green: Compressor is on
LED lights up orange: Compressor is off
3 ERROR LED flashes red: Device is switched
on but not ready for
operation
4 SET Selects the input mode
- Temperature adjustment
- °Celsius or °Fahrenheit display
5 – Display, shows the information
6 UP + Press once to increase the selected value
7 DOWN – Press once to decrease the selected value
CF-32UP.book Seite 32 Donnerstag, 16. Juli 2009 5:21 17
