WAGNER GM 5000EAC - Page 45

45
GM 5000EAC.
9
10
B_03208
B_03207
SW3
0.8 Nm
SW12
SW12
2
R1
R3
R2
OPERATING MANUAL
EDITION 03/2012 PART NUMBER DOC 2319150
Flat jet nozzle
Assembly see chapter 10.3.1.
Diverse nozzle sizes see chapter 9.2.
Round jet nozzle
Assembly see chapter 10.3.2.
Diverse nozzle sizes see chapter 9.1.
Ensure the correct
insertion position!
