WAGNER HT3500 User Manual

English
6 © 2004 Wagner Spray Tech. All rights reserved.
USING THE HEAT GUN
Many variables affect heating applications, such as the material being heated, ambient
temperature, the distance from the gun to the substrate and the heating technique. For this
reason, Wagner has provided temperature guidelines for certain applications. Always start
the heat gun at the lowest temperature in the range then raise the temperature until the
optimum temperature is achieved. Always keep the heat gun in motion and at least 2” from
the substrate when applying heat.
Always read the safety information included in this manual before
using the heat gun.
1. Plug the unit into a standard wall outlet.
2. Turn on the heat gun by pressing the
POWER
switch on the touch pad (A). When the gun is
turned on, it is automatically set in the
LOW
temperature range (B) at 850ºF (C) as shown.
3. If you wish to continue working within the
LOW temperature ranges, simply press the
arrows on the touch pad until your desired temperature setting is indicated by a light.
4. If you wish to operate within the
HIGH temperature ranges, press the SELECT
button once. The HIGH temperature range indicator light will turn on. You can now
press the arrows on the touch pad until you reach your desired temperature.
If the blower motor in the heat gun does not turn on when the
POWER button is activated, turn the switch OFF immediately. The
heating element will burn out if it is not cooled by the blower.
5.
During rest periods or when you are finished with your project, press the
SELECT
button until the COOL indicator light turns on (press once if working in HIGH
temperature settings, twice if working in LOW temperature settings).
6.
Set the gun down in an upright position.
The heat gun will shut itself off after a
certain cool-down temperature is reached.
Note: Smoke may appear during the initial start up due to the burning of
manufacturing oils. The smoke should disappear in less than a minute.
B
HIGH
LOW
1350
1250
1
1
5
0
1
0
5
0
950
850
750
650
550
450
3
5
0
2
5
0
POWER
COOL
HIGH
LOW
SELECT
C
A
Use Temp. Setting
Removing: Floor coverings (adhesive backed) . . . . . .350º - 750º F
Paint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .750º - 1150° F
Drying: Paint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250° - 550º F
Plaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250° - 550º F
Heating: Shrink-tube (electrical) . . . . . . . . . . . . . . . .350° - 650º F
Shrink-wrap (windows, crafts) . . . . . . . . . .250º - 550º F
Frozen locks . . . . . . . . . . . . . . . . . . . . . . . .350° - 650º F
Frozen water pipes . . . . . . . . . . . . . . . . . .1150° - 1350º F
Loosening rusted bolts/nuts . . . . . . . . . . . . . . . . . . . . . .1150° - 1350º F
Molding and bending plastics . . . . . . . . . . . . . . . . . . . . . .250° - 650º F
Molding and bending Plexiglass and Formica . . . . . . . .250° - 450º F
Waxing skis .and snowboards . . . . . . . . . . . . . . . . . . . . .250° - 450º F
Sealing ends of nylon rope . . . . . . . . . . . . . . . . . . . . . . . .450° - 650º F
Defrosting refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . .450° - 750º F
Heat Gun Model HT3500
CAUTION
CAUTION
