41
small screwdriver into the hole and adjust
the DRY BOX ZERO until the needle
rests precisely on the lower edge of the
DRY BOX (Figure 3).
Physical Zero
Figure 1
Dry Box Zero
Figure 2
Physical Zero—
Adjust until needle
sits on lowest
mark.
Figure 3
Dry Box Zero—
Adjust until needle
sits on edge of Dry
Box.
